Cradlepoint W1855 Series 5G Wideband Adapter
Outdoor 5G adapter designed for mid-band cellular as primary or failover connectivity
BE0x-1855-5GC-GN
Our Price: $1,949.00
Our Price: $2,249.00
Our Price: $2,549.00
Our Price: $2,049.00
Our Price: $2,549.00
Our Price: $3,049.00
Click here to jump to more pricing!
Overview:
When fiber is not an option or link diversity is needed
The W1855 Series 5G Wideband Adapter provides industry-leading Wireless WAN connectivity for optimal signal reception from outdoor installations on buildings and temporary sites that require high bandwidth, when fiber is not an option or link diversity is needed. Other use cases include high-performance cellular connections in SD-WAN, high-performance failover in medium-sized sites, and video broadcasts. This adapter uses a 3GPP Release 16 modem that includes the latest 5G standards.
Designed for fixed locations that require the higher performance of 5G and the flexibility of wireless, the outdoor Cradlepoint W1855-5GC Wideband Adapter ushers in the latest generation of wireless WAN networking. The W-Series is designed to accommodate the latest spectrums, recent innovations, and breadth of new technologies in 5G while delivering enterprise-class scalability standards, comprehensive management, and security.
Passthrough Throughput:
2 Gbps
Dual Connectivity:
5G Low/Mid-Band & Cat 19 LTE
LAN Connectivity:
2.5 GbE
Management:
NetCloud
Notable Features
- Increase the size and types of your WAN use cases with 5G performance
- Experience the dependability of dual connectivity with simultaneous 5G and 4G connections
- Gain carrier-class connectivity using a software-defined modem and integrated multilevel test and recovery utilities
- Deploy an enterprise-class 5G solution with greater simplicity and confidence with the wizard-based installation application
- Manage the Cradlepoint router and 5G adapter as one entity for singular control and visibility with captive modem
- Evaluate the benefits of your 5G service with value confirmation tools built into the NetCloud Platform
- Deploy within any existing networking or SD-WAN environment
High Performance Wideband
The W1855-5GC adapters are purpose-built for outdoor deployment in the high-performance low-, mid-band 5G spectrum. To address the tradeoff of lower propagation in the mid-band spectrum, Cradlepoint designed the W1855 Series outdoor adapter to be placed separately from the router for optimal signal reception. The stylized W1855-5GC adapter is less than half the size of the previous outdoor 5G adapter which makes installation easier.
Designed for Enterprise-Class Business
While the performance of 5G is top of mind, the W-Series was also designed with enterprise-class standards for high scalability, comprehensive management, and security. Representing the latest available 5G standards which are a collection of spectrum, technologies, and network infrastructure enhancements, the Cradlepoint 5G edge networking service and endpoints accommodate the diverse deployments of an organization with hundreds or even tens of thousands of sites.
Features/ Capabilities:
Carrier-Class Connectivity
Although each network operator conforms to 3GPP standards, they implement those standards differently to gain optimal efficiency and performance from their network. Additionally, software from modem manufacturers is designed to serve multiple operators within broad markets. The W-Series uses a customized software-defined modem, pre-programmed endpoints, and multilevel integrity testing to predict vulnerable connections and deliver carrier-class connectivity.
5G Spectrum Solutions
The W1855 5GC Series supports low- and mid-band 5G spectrum ensuring that organizations have access to the 5G layers that are most widely used globally. These layers offer a balance of speed, capacity, coverage, and propagation that works with bandwidth-intensive and latency-sensitive use cases.
Support for a Full Range of Cellular Technologies
Cradlepoint 5G solutions support all cellular generations, from 4G LTE to Gigabit-Class LTE to 5G — with the ability to gracefully transition tens of thousands of sites between generations as technology becomes available in individual locations.
Complete Lifecycle Management
Cradlepoint 5G solutions help enterprises minimize complexity from installation to troubleshooting with tools and features such as the mobile installation application, the captive modem feature, 5G tools demonstrate 5G service value, and Out-of-Band Management.
Intelligent Hybrid WAN Connectivity
Cradlepoint 5G solutions deliver effortless wireless endpoint management in a “wired-first SD-WAN” environment and provides all-in-one capabilities (routing, embedded wireless, and foundational SD-WAN) in a “wireless-first SD-WAN” deployment.
Hardware Specifications:
| W1855 Series 5G Wideband Adapter Specifications | |
|---|---|
| Category | Branch |
| Cloud Management | NetCloud |
| Wireless Connectivity | Dual Connectivity, 5G Low/Mid-Band & Cat 19 LTE |
| Form Factor | Metal (IP67 rated) |
| USB Ports | 0 |
| Serial Ports | 0 |
| Dual-Modem Support | No |
| Network Operator Standards | PTCRB (U.S.), GCF (global) |
| Network Operator Certifications | AT&T, T-Mobile, Verizon |
| Public Safety Networks | FirstNet Trusted, T-Mobile Connecting Heroes, Verizon Frontline |
| IP Passthrough Mode Throughput | 2 Gbps |
| Standard NAT Mode Throughput | 2 Gbps |
| Captive Modem Mode Throughput | 2 Gbps |
| Modem | Embedded 5G FR1 NSA/SA 3GPP release 16 and 4G LTE Category 19 modem |
| Ethernet | 2 x 2.5 GbE RJ45 (LAN/WAN switchable) |
| Bluetooth | Inactive, for future use |
| Wi-Fi | N/A |
| GNSS/GPS | Passive |
| PoE | 802.3at |
| Operating Temperature | -30 °C to 70 °C (-22 °F to 158 °F) |
| Ingress Protection | N/A |
| Ingress Protection/Corrosion |
|
| Wind/Lightning |
|
| Size | 204 x 165 x 56 mm (8.03 x 6.5 x 2.2 in) |
| Weight | 1.3 kg (2 lb 13.8 oz) |
| Enterprise-Class Modem Specifications | |
|---|---|
| Technology | 5G FR1 NSA/SA
|
| 3G | WCDMA/HSPA+ |
| Carrier Aggregation | LTE Only
LTE + 5G NR ENDC
5G NR Only
|
| Peak Rates | NSA
SA
LTE
|
| MIMO | 4x4 MIMO |
| Modulation | 5GC FR1
|
| 4G/LTE Bands | FDD
TDD
|
| 5G NR Bands | NSA and SA: n1 (2100), n2 (1900), n3 (1800), n5 (850), n7 (2600), n8 (900), n12 (700), n13 (700), n14 (700), n18 (850), n20 (800), n25 (1900), n26 (850), n28 (700), n29 (700), n30 (2300), n38 (2600), n40 (2300), n41 (2500), n48 (3500), n66 (1700/2100), n70 (2000), n71 (600), n75 (1500), n76 (1500), n77 (3700), n78 (3500), n79 (4900) |
| 3G Bands | B1, B2, B4, B5, B8, B19 |
| Power | LTE
5G NR
|
| Antennas | N-type female connectors, external 600 MHz - 6 GHz cellular antennas (Qty 4, included) |
| GNSS | Passive GNSS - GPS, GLONASS, BeiDou, Galileo |
| SMS | Yes |
| Regulatory | FCC (U.S.), IC (Canada), UK CA (UK), RCM (AU/NZ) |
| Network Operator Standards | PTCRB (U.S., Canada), GCF (Worldwide) |
| Network Operator Certifications* | AT&T, T-Mobile, Verizon |
| Public Safety Network Certifications | FirstNet Ready™ (LTE now, 5G pending), T-Mobile Connecting Heroes, Verizon Frontline |
| Private Cellular Network | Yes, includes FCC Part 96 (CBRS Band 48) |
* Cellular carriers and operators throughout the world may only require telecom industry certifications, like PTCRB or GCF, to operate on their network. Some carriers require additional testing and approval, beyond telecom certifications, to operate on their network. A carrier listed in the approvals section means Cradlepoint completed additional testing and acquired technical approval for that given carrier. Any carrier not listed may not require additional testing or approval beyond telecom industry certifications to operate on their network.
Software Features:
Software feature availability depends on the service plan selected. Learn more about the NetCloud Service packages.
Cellular Intelligence
- Cellular health with live stats and diagnostics
- Carrier selection intelligence
- Location services with serving cell tower
- Carrier data usage management and alerting
Cloud Management
- Zero-touch deployment
- Network visualization and monitoring
- Bulk configuration and software updates
- Live stats for cellular
- Multi-layered dashboards and shareable reports
- User and license management
Private Network Compatibility
- NetCloud Private Networks
- Ericsson Private 5G
Remote Troubleshooting
- Real-time diagnostics and alerts
- Integrated 5G speed test with results history
- In-Band Management for third-party LAN devices
Documentation:
Download the Cradlepoint W1855 Series 5G Wideband Adapter Datasheet (.PDF)
