RackMount Kit for Cradlepoint E300


RM-CR-T1:

All rack mounts are subject to the availability of given stocks and can vary significantly
based on the timing and the size of the order.

Pigtails not included
The RM-CR-T1 gives you the ability to mount your desktop appliances in a 19" rack. The rack is tailored specifically for the listed models to guarantee a perfect fit. In addition, the connections are brought to the front for easy access, as well as the console port. The power supply is fixed to prevent an accidental loss of power.

Assembly will take about 5 minutes. Simply slide your device in the kit, place the retainers, connect the supplied cables and keystones, and fix the power supply to the rack.

Other colors can be delivered on a project basis.

Image Views:

Specifications
Manufacturer	Rackmount.IT
Model	Cradlepoint
For Use	Cradlepoint E300
Color	RAL 9005 Black
Height	1.3U / 2U
Dimensions (height x width x depth)	2.32/3.46 x 18.98 x 8.54 in. (59/88 x 482 x 217 mm)
Number of connections brought to the front	7
Console port to the front	Yes
Cables	6x 0.5m cables
Couplers	5x RJ45 couplers 1x USB Couplers 1x Fiber Couplers
What's in the box	1x CR-Rack + couplers 1x Rackmount.IT front plate Cables Assembly materials Installation guide

Download the RM-CR-T1 Datasheet (PDF).
